SUB600s are able to deliver outstanding sound pressure levels in spite of their compact housing, while providing a clean, impressively precise low-end reproduction.
Features
- 600 W RMS Class D AMP
- Selectable Stereo Balanced Input
- Link or Xover Balanced Stereo Output Mode
- Compact and sturdy wood cabinet
- Lightweight
- Polarity Switch
- FLAT or BOOST Mode Switch
Technical Data
Speaker Type: Active Subwoofer
Acoustical data
Frequency Response [-10dB]: 42 – 124 Hz
Max SPL (1 m): 131 dB
Directivity: omnidirectional
LF: 15″
LF Voice Coil: 2.5″
Amplifier
Amp Technology: SMSP digital amplifier
Amp Class: Class D
RMS Power: 600 W
Peak Power: 1200 W
Processor
Controller: 28/56 bit DSP
Limiter: Peak, Thermal, RMS
Controls: Subwoofer level, Outputs mode, Polarity, Subwoofer mode
Input
Signal Input: 2x XLR (balanced)
Signal Output: 2x XLR (balanced)
Mechanics
Housing: Plywood
Grille: Full metal grid
Pole Mount: M20
Width: 430 mm (16.92 in)
Height: 580 mm (22.83 in)
Depth: 600 mm (23.62 in)
Weight: 25.5 kg (56.22 lbs)
